Overview

Blend Craft Compositor is a Blender addon designed to streamline and enhance the compositing workflow by automating the setup of essential render passes and providing intuitive controls for post-processing effects. This addon is specifically designed for Cycles and does not support Eevee.

Installation

How to Install & Activate the Addon:

- Download the Blend Craft Compositor ZIP file.
- Open Blender, go to Edit > Preferences > Add-ons.
- Click the Install button, then locate and select the downloaded ZIP file.
- Enable the addon by checking the box next to its name.
- Go to the Compositor Tab in Blender.
- Press N to bring up the side panel.
- Locate the '3DT Compositor' tab on the right to access the addon's controls.

Main Controls

Setup Compositor

• Function: Automatically enables all necessary render layers and sets up a node group in the compositor.

• Purpose: Simplifies the post-processing workflow by connecting all relevant passes for easy control.

Presets Tab

• Save and export presets as JSON files, which can be imported into other Blender projects.

• Includes a "Load Defaults" button to reset all options to their default values.




Background Tab

• Transparent Background: Enables alpha transparency for the render.

• Custom Image Background: Allows the addition of a custom image as the render background with adjustable controls.

• No Transparency: Keeps the default opaque background.




Gloss Tab

• Provides curve controls to adjust highlights.

• Includes brightness, contrast, and metal glint controls for reflective surfaces.

Mist Tab

• Adds a mist layer to the scene with adjustable depth and color controls.




Color Tab

• Adjust hue, saturation, and value (HSV) of the base layer.

• Includes a curve editor for fine-tuning color adjustments.

Transmission Tab

• Adjust transmission effects with:

  • Curve controls

  • Lift / Gamma / Gain adjustments

  • Light level settings




Volume Tab

• Fine-tune volumetric effects with:

  • Color adjustments

  • Curve controls

  • Gradient customization

Light / Bloom Tab

• Adjust bloom intensity and select bloom type.

• Configure:

  • Bloom strength

  • Lens streaks toggle

  • Bloom color

  • Threshold for bloom effect

Environment Tab

• Control the brightness, lift, gamma, and gain of the world shader in the background.

Ambient Occlusion Tab

• Adjust depth and color settings for ambient occlusion to enhance shading realism.

Effects Tab (Post-Processing Effects)

This tab includes a variety of post-processing effects applied after the main compositor setup:

• Diamond Sharpen – Enhances edges with a diamond sharpening filter.

• Box Sharpen – A subtle sharpening effect for overall clarity.

• Soften – Reduces harsh edges and blends details smoothly.

• Anti-Aliasing – Minimizes jagged edges for a cleaner render.

• Color Balance – Adjusts shadows, midtones, and highlights for precise color control.

• RGB Curves – Allows post-processing color grading.

• Hue Correct Curve – Enables selective color correction.

• Brightness / Contrast – Adjusts overall image brightness and contrast.

• Hue / Saturation / Value – Fine-tunes color intensity and tone.

• Denoise – Provides two denoising options:

  • Accurate (Higher Quality, Longer Render Time)

  • Fast (Lower Quality, Faster Render Time)




Accessing the Shader Setup

The Blend Craft Compositor node setup is fully accessible within Blender’s Compositor Editor. All nodes are organized and clearly labeled for quick and easy adjustments. This structured layout ensures that users can navigate through the compositing process efficiently, making modifications or adding custom effects without disrupting the core setup.
