Zform - Convert Depth Maps And Images To 3D Mesh
Viz Life Studio
New Documentation Page
Please visit my new documentation page that covers an extensive amount topics including installation, user interface, how to use features, tips and tricks, and updates. Going forward this will be my primary source of adding new documentation.
https://vltools.github.io/zForm/overview/
Quick Getting Started Guide
As a starting point, here's a quick getting started guide to using zForm that covers all the key areas including installation and using key features. It's very possible this video is sufficient to get you ready to go. Please also take a look at the very bottom of the Documentation page for more tutorials to use Video and Directory features, tips and tricks.
Newest Updates and Releases
https://vltools.github.io/zForm/updates/
zForm Tutorials
| Title | Description | Video Link |
|---|---|---|
| Playlist of Tutorials | Here's where you can go to see all the latest tutorials released about Depth Map Batch. | Watch |
| Intro to zForm | Here's a quick intro for zForm and what the tool does. | Watch |
| Installing and Getting Started with zForm | Here's a guide on installing and getting started with the tool. | Watch |
| Remove back side of mesh | To remove the back side of a mesh try following the steps here. | Watch |
| Video file | Steps to import a video file and the corresponding depth map video. | Watch |
| Directory feature | Here's a guide on using the Directory feature. Make sure the corresponding depth maps for each image match the original image file name except it will have "_depth" at the end. Also use Blender's Timeline for each frame to go to the next image. | Watch |
Saving and Working with Project Files for zForm
I discovered that the “Relative Paths” setting in Blender’s Preferences was causing problems when reusing saved projects. To fix this, please follow these steps:
- Open Blender and go to Edit → Preferences.
- In the Preferences window, navigate to the Save And Load section.
- Uncheck the "Relative Paths" option in the Default To section.
- In the bottom left of the Preferences window, click on the hamburger icon to save your preferences.
This change will be saved for all future project files. If you ever need to revert to the previous behavior, simply re-check the "Relative Paths" option.
Additional Note for zForm Users:
When reopening an older project in zForm, please note that the Mesh View option defaults to top view. You may need to adjust this setting manually.
Below is a snapshot to help illustrate these steps.
